Forged Steel Trunnion Mounted Full Welded Stainless Ball Valve 锻钢固定全焊接不锈钢球阀

applicable medium：water
适用介质：水
material：carbon steel，stainless steel

材质：碳钢，不锈钢
type of connection：flange

连接方式：法兰，对焊接
drive mode：manual，worm gear

驱动方式：涡轮，人工操作
nominal pressure：ANSI class150-600

公称压力：ANSI class150-600
aisle：straight through type

通道：直通型
type of construction：fully welded

结构形式：全焊接
category：ball valve

类别：球阀
function：blow-down valve

功能：排气阀
temperature：normal temperature

温度：普通温度
standard：API 6D,ASME B16.34

标准：API 6D,ASME B16.34
application：industrial usage

应用：工业用途
transport package：plywood case

运输包装：胶合板箱
specification：50KG/PC

规格：50KG/PC
brand：GUTE

商标：GUTE

Fully welded ball valve, no external leakage phenomenon.
The machining process of the ball is tracked and detected by the advanced computer detector, so the machining precision of the ball is high.
As the valve body material is the same as the pipe material, there will be no uneven stress and deformation due to earthquake and vehicle passing through the ground, so the pipe is anti-aging.
The seal ring body is made of RPTFE with 25%Carbon, ensuring complete leakage free (0%).
Directly buried welding ball valves can be directly buried in the ground, do not need to build high large valve Wells, only set small shallow Wells on the ground, greatly saving construction costs and engineering time.
The length of the valve body and the height of the stem can be adjusted according to the construction and design requirements of the pipe.
The ball machining precision is very precise, easy to operate, no bad interference.
Adopt high quality raw material, can protect the pressure above PN25.
Compared with the same specifications in the same industry, the valve body is small and beautiful in appearance.
Under the condition of normal operation and use, the service life of the valve should be more than 20 years.

全焊接球阀，无外漏现象。

球的加工过程由先进的计算机探测器跟踪和检测，因此球的加工精度高。

由于阀体材料与管道材料相同，不会因地震和车辆通过地面而产生不均匀的应力和变形，因此管道具有抗老化性。

密封圈阀体采用含25%碳的RPTFE材料，保证完全不泄漏(0%)。

直埋焊接球阀可以直接埋在地下，不需要建高的大型阀门井，只需在地上设小的浅井，大大节省了施工成本和工程时间。

阀体的长度和阀杆的高度可根据管道的结构和设计要求进行调整。

滚珠加工精度非常精确，操作方便，无不良干扰。

采用优质原材料，可保护PN25以上压力。

与同行业相同规格相比，阀体外形小巧美观。

在正常运行和使用的情况下，阀门的使用寿命应在20年以上。
